| apply | Brittle, soil, fiber, strong oxidation, corrosive powder pollution-free grinding | application area | Medicine, medicine, food, chemicals, synthetic materials, electronics, engineering, metallurgy, glass |
| sample characteristic | Soft / hard material, brittle material | The principle of crushing | Friction force, collision force |
| Milling method | Dry method or wet method | cryogrinding | customizable |
| Vacuum grinding | yes | Conventional crushing time | 15-25min |
| Feed size | ＜4mm | Finishing particle size | 0.1um |
| Maximum grinding amount of the batch | 2L | Number of grinding platforms | 4pcs |
| ratio of transmission | 1:-2 | Ball grinding tank speed | 600r/min |
| Ball grinding tank type | utility-type | noise | 55-70 db (depending on the ground ball and the sample) |
| Ball grinding tank material | Stainless steel / nylon / polyurethane / teFE / polypropylene / polyethylene / agate / alumina / zirconia, etc | Ball grinding tank size | 100ml-500ml |
| Grinding ball material | Stainless steel / alumina / zirconia / calcium carbide, etc | Grinding ball size | 3mm-20mm |
| Touch screen function |
| operator schema | High touch touchscreen (standard) | hand operation | Can be forward, reverse, stop, manually set the speed and other routine functions |
| Program operation | 5 section speed of operation can be to run forward (time can be set), reverse running (time can be set), alternating running, intermittent running (time can be set), time grinding (time can be set), pause, program period and time monitoring, also for customers to write, read call custom formula more human function |
| defencive function | With program memory, power failure memory, fault code prompt and other auxiliary protection functions, to ensure the use of customer requirements |
| Grinding time setting | Numbers display, 00:00:01 to 99:59:59 | Pause time setting | Numbers display, 00:00:01 to 99:59:59 |
| Interval operation time setting | Numbers display, 00:00:01 to 99:59:59 | drive | Frequency converter, three-phase AC motor |
| driving power | 0.75kw | driving voltage | 220V |
| Motor frequency | 50Hz | mains connections | uniphase |
| Body size (width * depth * height) | 685*420*405 | net weight | About 96kg (no tank and pendant weight) |
| appendix | Hanging gear, 14 mesh screen, belt, disassembly tools, manual, warranty card, certificate. | | |
